DJI BS100 Battery Station — Rapid, Intelligent Charging for Matrice 400

Turn batteries faster and keep critical missions in the air.
The DJI BS100 Battery Station streamlines fleet charging for the DJI Matrice 400 Series. Charge up to three TB100 Intelligent Flight Batteries and two WB37 remote controller batteries at once, choose fast or quiet modes, and use smart charge profiles (90% or 100%) to balance readiness and battery health. Built tough for field work, the BS100 is your hub for public safety, surveying, inspection, and industrial operations.

Why choose the BS100

• Multi-bay efficiency: Charge 3× TB100 + 2× WB37 simultaneously; compatible with TB100C Tethered Battery.

• Rapid turnaround: Fast Charging Mode delivers a full charge in ≈45 min @ 220 V or ≈70 min @ 110 V; Silent Mode completes in ≈110 min (both voltages).

• Smart power management: Ready-to-Fly (90%) to extend longevity and launch sooner, or Standard (100%) for maximum capacity.

• Flexible input: 100–240 V AC wide-range power for global deployments.

• Field-ready build: Rugged, portable case for harsh environments; designed for mobile teams.

Key specs

• Supported batteries: TB100 (Matrice 400), WB37 RC batteries; compatible with TB100C Tethered Battery

• Charging modes: Fast Charging, Silent Mode, Ready-to-Fly (90%), Standard (100%)

• Charge times:

  • Fast Charging: ~45 min @ 220 V, ~70 min @ 110 V

  • Silent Mode: ~110 min (110 V / 220 V)

• Power input: 100–240 V AC

• Operating temperature: −20° to 40°C

• Dimensions (case): 605 × 410 × 250 mm

• Weight: 11.8 kg

Ideal use cases

• Public safety & SAR readiness

• Utility & infrastructure inspection

• Surveying, mapping, and construction progress

• Long-duty shift operations with rapid battery rotations

What’s in the box

• 1× DJI BS100 Battery Station (case-integrated)

• Power cable and documentation (contents may vary by region)

Pro tips

• Use Ready-to-Fly (90%) for standby fleets to improve long-term health and reduce time to launch.

• Rotate battery sets and log cycles to maximize lifespan across your pack inventory.

FAQs

Can the BS100 charge flight and controller batteries at the same time?
Yes. It supports 3× TB100 plus 2× WB37 simultaneously.

What mode should I use for standby vs. full missions?
Use Ready-to-Fly (90%) for standby to reduce stress on cells. Choose Standard (100%) when you need maximum endurance.

How loud is Silent Mode?
Silent Mode lowers fan noise for indoor or command-center environments and completes a full charge in ~110 minutes.

Is the BS100 compatible with earlier Matrice batteries?
The BS100 is designed for TB100 (Matrice 400 Series) and WB37. Check legacy systems for their specific stations.
